Fusion MS-RA60 Marine Stereo With Wireless Connectivity

Modern, compact and the most economical marine stereo from Fusion yet.

Sources: AM / FM / Bluetooth / AUX / DAB+

The MS-RA60 is Fusion’s most economical marine stereo yet, featuring modern aesthetics, Multi-Zone technology in two zones and advanced connectivity options in a compact form factor. Designed for quality audio entertainment in the harsh marine environment, a perimeter bonded, anti-fogging LCD is integrated into the IPX6 and IPX7 water resistant black front face – making the MS-RA60 an attractive addition to your helm.

Features:

Multi-Zone Technology: Up to two independent audio zones are available for a customized listening experience across your boat, each with advanced localized audio options, including volume limits, zone naming, tone control, balance and more.

IPX6 and IPX7 Ingress Protection: The front panel of the MS-RA60 meets international IPX6 and IPX7 Water Ingress Protection standards, providing assurance that your product will perform and last in the harsh marine/outdoor environment when installed correctly (please refer to the installation instructions for specific details).

Retrofittable: The MS-RA60 is designed to fit in the MS-RA55 mounting profile, eliminating the need to alter your existing cutout, reducing complexity when upgrading your stereo system.

Class-D Amplifier Design: The built-in Class-D amplifier provides increased power while drawing less current than a standard Class-AB amplifier. The amplifier design delivers increased efficiency and power output, letting you enjoy your music at higher volumes for longer.

Wireless Software Updates: Over-the-air software updates are now available from your compatible device via BLUETOOTH with the free Fusion-Link app, making it simple to keep the MS-RA60 up to date.

Fusion-Link Control (Wireless) via BLUETOOTH and ANT: Download the free Fusion-Link remote control app for BLUETOOTH from the Apple App Store or Google Play and enjoy the freedom of wireless control from your compatible device. Download the free Fusion-Link Lite app from the Connect IQ app to enable wireless control via ANT technology from your compatible Garmin watch.

2.3′ Bonded Monochrome LCD: The monochrome LCD is perimeter bonded to improve durability and protection against condensation and fogging and is optimized for daylight viewing.

Modern Design Aesthetics: The monochrome LCD is incorporated into a black front face for ease of visibility and enhanced styling. The black front face blends in seamlessly with your dash, complementing other electronics and MFDs for a tidy, uniform and elegant installation.

Built-In DAB Module: The built-in DAB module supports the latest DAB and DAB+ broadcasts, allowing you to enjoy high quality digital radio streaming wherever DAB and DAB+ is supported (Europe and Australia only; does not support traffic and weather). Simply connect an appropriate AM/FM antenna with no external DAB module required.

Specifications:

Physical Dimensions (WxHxD)	6.18 x 2.68 x 4.06 (156.9 x 68 x 103.2 mm)
Weight	11.1 oz (316 g)
Water Rating	IPX6 and IPX7 (front panel only, when properly installed)
Power Input	10.8-16 VDC
Operating Temperature Range	32 degrees to 122 degrees F (0 degrees to 50 degrees C)
Current (Max.)	15 A
BLUETOOTH Wireless Range	Up to 30 ft (10 m)
ANT Wireless Range	Up to 10 ft (3 m)
Wireless Frequencies/Protocols	BLUETOOTH 2.4 GHz @ +12 dBm nominal / ANT 2.4 GHz @ +7 dBm nominal
Compass-Safe Distance	5.9 (150 mm)
Display	2.3 perimeter bonded monochrome dot matrix LCD
Built-In Amplifier	Class-D (minimum 4 ohm impedance)
Peak Power	180 W
Rated Power Output (4 ohm)	22 W rms x 4 @ 14.4 V input, 4 ohm, 10% THD
Fusion-Link Control	Yes (with compatible Apple and Android devices)
Fusion-Link Lite Control	Yes (with compatible Garmin watch)
Multi-Zone Technology	2 zones
BLUETOOTH Wireless Technology	Yes
ANT Wireless Technology	Yes
DAB+	Yes (DAB tuner built-in)
Multi-Language Interface	Dutch / English / French / German / Italian / Spanish
Software Updates	Over-the-air software updates via BLUETOOTH wireless technology using the Fusion-Link app
Warranty	1 year
Sources	AM / FM / BLUETOOTH / AUX x1 / DAB+ (available in Europe and Australia only)
Auxiliary Input	One RCA input (AUX)
AM / FM Radio	One Motorola antenna connector port
Speaker	4 x speaker connections (2 amplified zones)
RCA Pre-Out (Left, Right and Subwoofer)	1 zone (requires external amplification)
Line Out	Zone 1: L + R (requires external amplification)
Subwoofer Out	Zone 1 (requires external amplification)
