Fusion 6-Channel Marine Amplifier 1600W 24V

The Fusion AM Series Marine amplifiers are purpose built for the
marine environment, boasting some of the most impressive
environmental protection available, to deliver performance on the
water like never before.

The MS-AM806 is a 24V amplifier.

Incorporating heat-tempered and conformal coated PCB’s for
maximum product life and gold plated connectors for improved signal
flow – The result is a clean and powerful reproduction of the input
signal, delivering enough power to rock the boat.

The 6 Channel 1600 Watt (Peak) MS-AM806 design ensures clean and
powerful amplification of the input signal. It has unlimited
configuation options available to help spread the sound around your
vessel:

• 3 pairs of speakers (6 speakers)
• 6 pairs of speakers (12 speakers) wired in parallel at 2 Ohms
  (2 x 4 Ohm speakers per channel)
• 1 Subwoofer (bridged) and 2 pairs of speakers ( 4
  speakers)
• 2 Subwoofers (4 bridged channels) and a pair of speakers (2
  speakers)

Features:

• FUTRANZ Heat Sink Technology, which transfers heat more
  efficiently and offers more thermal stability and maximum component
  reliability.
• F.R.A.T Fusion Regulated Amplifier Technology, which outputs
  enormous power output at the lowest voltage
• F.I.S.T Fusion Intercooled Semi-Conductor Technology, which
  clamps down internal power switching – rapidly removing heat from
  all associated semi-conductors
• The Fusion AM Series Marine amplifiers are the perfect
  complement to any Fusion Marine stereo system.

Specifications:

Frequency Response	5Hz – 38kHz +/- 3dB
Peak Power	1600 Watts
Rated Power	28.8 Volt power output specs 80 Watts RMS x 6 @ 4ohm 1% THD+N, 130 Watts RMS x 6 @ 2ohm 1% THD+N, 275 Watts RMS x 3 @ 4ohm Bridged 1% THD+N

Mountign Dimensions

Depth	299mm [9”]
Height	53mm [2-1/16”]
Length	390mm [15 3/8”]

User/Installation Manual
